    Power Steering: Any DIYs? Worth the effort?

    I'm tinkering with the idea of converting my Series IIa to power steering. However the problem lies with who to ask information about this. The body and engine (2.5L) are from a Series IIa. However my transmission and transfer case (LT77 & LT230) are from a Defender. The axles and suspension are also from a Defender, sitting on a galvanized chassis.

    So with that said, anyone have any tips/ideas on where I could go with this?

    1971 Series IIa Hybrid: 2.5L MILSPEC 5-Main Bearing Engine|Turner Engineering Performance Head w/ oversized hardened steel valves & phase shift/increased lift cam|LT77 Tranny/LT230 Transfer Case|11mm Ignition Wires/Super Coil|Jacobs Ignition/Petronix Ignitor|D90 Axles|Galvy Frame|Old Man Emu Coils|Cust Rear/Side Fuel Tanks|Cust Drive Shafts|
  • LaneRover
    Overdrive
    • Oct 2006
    • 1743

    #2
    Check out Terri Ann's very informative site.



    Thats the power steering link, but there is a lot more info on her site.
    1958 107 SW - Sold to a better home
    1965 109 SW - nearly running well
    1966 88 SW - running but needing attention
    1969 109 P-UP

    http://www.facebook.com/album.php?ai...2&l=64cfe23aa2

    Comment

    • KevinNY
      4th Gear
      • Oct 2006
      • 484

      #3
      It isn't hard on a leafer but the coil chassis makes it much more difficult. I have a designa coil chassis 88 with power steering but the solution was quite involved including cutting out the front chassis member and fabbing a new one that sits further forward and a new radiator panel support.
      The Goat, 2.8 Daihatsu Td, '73 coil conversion

      Comment

      • bbrigman
        Low Range
        • Jan 2009
        • 6

        #4
        The boys at rover automotive in Durham rigging one now

        Saw them just last week putting unit in an 88.
        Tole me price was as yet tbd
        Brian

        Comment

        • greenmeanie
          Overdrive
          • Oct 2006
          • 1358

          #5
          As your truck is a hybrid we'd need a few pictures. TAW's site shows PS install on a leaf sprung series which may not be applicable on your truck if it has Defender axles as the steering linkage is different. Then again, if you have series manual steering the linkage may have been altered to work.

          Post some pictures of your truck showing the steering bars and the steering relay. Also post some pictures of the inside of the engine bay and the inside of the wheelarch on the driver's side. That will let us see what room you have to play with.

          Comment

          • NC Rover
            2nd Gear
            • Dec 2007
            • 288

            #6
            Originally posted by KevinNY
            It isn't hard on a leafer but the coil chassis makes it much more difficult. I have a designa coil chassis 88 with power steering but the solution was quite involved including cutting out the front chassis member and fabbing a new one that sits further forward and a new radiator panel support.
            Yes that does sound involved. Would it be possible to provide me with some pictures of your setup? Thanks!
            1971 Series IIa Hybrid: 2.5L MILSPEC 5-Main Bearing Engine|Turner Engineering Performance Head w/ oversized hardened steel valves & phase shift/increased lift cam|LT77 Tranny/LT230 Transfer Case|11mm Ignition Wires/Super Coil|Jacobs Ignition/Petronix Ignitor|D90 Axles|Galvy Frame|Old Man Emu Coils|Cust Rear/Side Fuel Tanks|Cust Drive Shafts|

            Comment

            • NC Rover
              2nd Gear
              • Dec 2007
              • 288

              #7
              Originally posted by bbrigman
              Saw them just last week putting unit in an 88.
              Tole me price was as yet tbd
              Brian
              I would be curious to see what the total price turns out to be. Also I'd like to know what power steering unit they went with?
              1971 Series IIa Hybrid: 2.5L MILSPEC 5-Main Bearing Engine|Turner Engineering Performance Head w/ oversized hardened steel valves & phase shift/increased lift cam|LT77 Tranny/LT230 Transfer Case|11mm Ignition Wires/Super Coil|Jacobs Ignition/Petronix Ignitor|D90 Axles|Galvy Frame|Old Man Emu Coils|Cust Rear/Side Fuel Tanks|Cust Drive Shafts|

              Comment

              • TeriAnn
                Overdrive
                • Nov 2006
                • 1087

                #8
                Originally posted by NC Rover
                I would be curious to see what the total price turns out to be. Also I'd like to know what power steering unit they went with?
                Right now the Range Rover P-38 is considered to be the hot set up. The P-38 is a good strong box that doesn't seem to leak. You can use the stock steering arm and lower steering shaft. Easier than dealing with the old stand by hard to find Scout II power steering box.

                The hard part with a 2.25L engine is mounting the power steering pump. One of the military 2 belt crank shaft pulleys comes in very handy.

                As an Alternative Heystee Automotive Components offers a complete power steering kit that uses a ram. This kind of conversion has been popular in Europe for decades.
                -

                Teriann Wakeman_________
                Flagstaff, AZ.




                1960 Land Rover Dormobile, owned since 1978

                My Land Rover web site

                Comment

                • tuko
                  Low Range
                  • Apr 2008
                  • 22

                  #9
                  I've been watching this thread for some time as I also plan to convert my series 3 Hybrid to power steering. Searching the internet has not produced any good or any results for P38 power steering boxes on a Series vehicle but I can see the advantages to having a power steering box bolted to the outside of the frame rail and it being Land Rover parts.

                  The plan that I have brewing is to get a P38 power steering box (ANR3242 or ANR5320 - RHD), then use a Defender steering column with Defender steering linkage to hook everything up. As for the drag link, I'm still looking but I'm thinking along the lines that having a Defender front axle, it I believe is the same width as a P38 front axle. So if that is true I should be able to use a P38 drag link to couple the steering to the front hub.

                  But with that said, Kevin have you've been able to sort out any pictures that have been requested? Seeing that you have the same frame as I have, it would be beneficial to see what you have done, even if it is LHD.

                  Also it has been mentioned on several occasions that Timm Cooper has been using the P38 box with success for some time now....But it appears to be only word of mouth, no pictures or write ups to be found anywheres. Is there anyone here that can point us who want to do this conversion in the right direction?


                  Cheers,
                  Todd.
                  My Series 3 Hybrid
                  300Di Powered
                  Småland Traxx - Offroad Aventure Tours. More info can be found on Facebook.

                  Comment

                  • LR Max
                    3rd Gear
                    • Feb 2010
                    • 315

                    #10
                    I guess I'll chime in.

                    So I got my rover converted to Power Steering about 4 years ago. My stock steering essentially blew up and I figured for the price of all new steering, I could do with power steering. You know, move forward rather than sideways.

                    Well, the guy who did my install was a COMPLETE HACK. So up until about a month ago I had all kinds of problems. Still, a semi-working power steering system turned out to still be SIGNIFICANTLY better than the manual steering...on a good day.

                    So now I've gotten my steering system re-worked and a new pump put on. I've still got some air bubble issues but other than that, it is COMPLETELY AWESOME. Seriously, I live in Atlanta. All parking areas are tiny and difficult to work in unless you drive a Smart or something else dismally dismal. With the power steering I can whip in and out of any spot anywhere, no problem.

                    Comment

                    • TeriAnn
                      Overdrive
                      • Nov 2006
                      • 1087

                      #11
                      Originally posted by tuko
                      Also it has been mentioned on several occasions that Timm Cooper has been using the P38 box with success for some time now....But it appears to be only word of mouth, no pictures or write ups to be found anywheres. Is there anyone here that can point us who want to do this conversion in the right direction?
                      I need to get a set of conversion pictures before I farther document the box on my power steering conversion web page. The process is the same as for the Scout II steering box conversion I have documented except that you use the P38 steering box, lower steering shaft and pitman arm.
                      -

                      Teriann Wakeman_________
                      Flagstaff, AZ.




                      1960 Land Rover Dormobile, owned since 1978

                      My Land Rover web site

                      Comment

                      • mongoswede
                        5th Gear
                        • May 2010
                        • 757

                        #12
                        I'll muddle out into this one and please point out the error of my thoughts:

                        Is this conversion any more complicated than attaching a power steering pump to the outside of the front left frame rail and attaching the appropriate steering arm? Mount a pump, some lines, and steering shaft?

                        I suppose I've simplified things as it does require a bit of cutting, drilling, welding, ujoint and steering shaft selection etc. fab a bracker for the power steering pump and choose a belt....I guess things could get tricky if the engine bay is tight.

                        pick away


                        I'll note that my hybrid consists of a shortened disco chassis and already has the mounting point for the power steering so its all easy. I looked at the engine bay on my 109 with the stock chassis and it looks like the pump would fit but require some inner fender mods.

                        Comment

                        • KevinNY
                          4th Gear
                          • Oct 2006
                          • 484

                          #13
                          It is very important to point out the difference between adding PS to a leaf sprung series chassis vs. a coil conversion chassis like a Designa brand. I can not speak of the conversion on a cut dowm disco or classic chassi. Teri and others have well documented the standard conversion on a series truck. The coil suspension mountings complicate things on a Designa chassis because because of the coil buckets on the frame and the pan hard rod bracket. The solution that Matt Browne at Overland Engineering came up with was to cut out the front crossmember and weld a new one he made up further forward and then fab a structural apron to support the breakfast while keeping everything inside the body.
                          The Goat, 2.8 Daihatsu Td, '73 coil conversion

                          Comment

                          • junkyddog11
                            1st Gear
                            • Feb 2007
                            • 195

                            #14
                            these are photos of the P38 box on a leaf sprung rig. Not sure of the relevance as it will not work on a coiler. The box can be hidden completely behind the radiator support. I have more photo's of the completed install that I can't find right now.........
                            Matt Browne
                            www.overlandengineering.com
                            "resurecting junk through engineering"

                            Comment

                            • junkyddog11
                              1st Gear
                              • Feb 2007
                              • 195

                              #15
                              A couple more photos of the Goats install. Used an RRC PAS pump and box. The alternator bracket design was borrowed from Ike Goss at Pangolin 4x4 and differed in that the alternator was moved forward to use the front part of the double pulley.
                              Note; For normal alternator conversions/relocations, I buy the bracket from Ike
                              ...and in an odd twist of fate, due to the Goats engine conversion, I have the pictured PAS pump installed on another build using a P38 box on a leafer, actually the one in the last post.
                              Matt Browne
                              www.overlandengineering.com
                              "resurecting junk through engineering"
